Enraged Rabbit Carrot Feeder: ender 3, Kit

The mainstay of your rabbit’s diet should be high-fiber grasses, but it’s typical to add timothy or oat hay as a supplement since they offer essential nutritional balance.

With the Fysetc Enraged Rabbit Carrot Feeder (ERCF) Kit, you may feed the printer toolhead with a large variety of filaments (we offer the 6 and 9 channels variants). The Voron Design M4 extruder serves as the foundation for the ERCF gear motion system, which is what is used to push and pull the filament. The Prusa MMU2 and the Smuff served as inspiration for the ERCF. Everything needed to build the ERCF is included in the kit, with the exception of the printed pieces.

Features:
  • Fully automatic filament switching for multi-color printing, with a large number of compatible filaments.
  • Modular assembly method allows flexible adjustment of the number of replaceable filaments based on your printing needs.
  • The ERB module is based on the RP2040 MCU and uses a power management chip. Compared with the competition, it generates less heat, has a higher power output, is more stable and uses an USB-C interface, so the device performance is improved.
  • the movement module has a chrome-plated optical shaft with engineered plastic bearings so that the device can run smoothly and quietly
Printer Compatibility:

Voron Trident, Switchwire & 2.4 printrers but also other Klipper based 3D printers

Bill Of Material:

The kit comes without printed parts!

6 channel version:

ProjectsComponent SpecQty
NEMA17 Motor 14HS11-1004S35 stepper motor 35*35*28mm1
NEMA17 Motor 17HS08-1004S42 stepper motor 42*42*20mm1
Towerpro MG90S servomg90 14g tooth digital servo (S version) 180°1
Heat Sinks9*9*12 black2
TCRT5000 Sensor PCB1
ERCF ERB1
jumper2.543
Omron Mouse Button Micro SwitchOmron mechanical limit switch D2F-01L1
AH3364Q-P-B Hall Effect sensor (SIP)1
xh2.54 male 3-pin header1
6mm x 3mm Round Neodymium Magnets1
M3 DIN125 Steel Washer1
M3x8 SHCS1
M3x12 SHCS1
N sets of bondtechs gearsBMG Gear Kit qty = N + 17
LM8UU bearings or RJ4JP-01-08LM8UU RJ4JP-01-082
M5 threaded rodsM5 Threaded Rod Length 156mm Length = 25 + N*21 + ceil(N/3 -1)*5 mm2
8mm smooth rods8mm Chrome Plated Smooth Shaft Length 171mm Length = 40 + N*21 + ceil(N/3 – 1)*5 mm2
D-cut 5mm shaftD-axis 5mm Length = 70 + N*21 + ceil(N/3 – 1)*5 mm1
MR623ZZ bearingMR623ZZ ball bearing1
MR85ZZ bearingsMR85ZZ Ball bearing5
M3 threaded insertsM3 D5 L435
M5x30 BHCS2
M5x16 BHCS1
M5 nuts5
M5 nylock nuts6
M5 washers3
M3x8 SHCS25
M3x8 BHCS5
M3x12 SHCS3
M3x16 SHCSqty = 4 + N13
M3x20 SHCS7
M3x40 SHCS2
M3 DIN125 Steel Washer11
M2x8 SHCS or M2x10 SHCS2
GT2 belt 6mm (open)GT2 Open Belt-2GT-6 (6mm width) – Gates Belt Length 450mm Length = 150 + N*42 + ceil(N/3 – 1)*10 mm1
GT2 20T Pulley 6 mm, 5mm bore3
GT2 20T Toothed Idler 6 mm, 5mm bore1
GT2 188m Belt loop 6mmGT2 Closed Belt (6mm W) – 188mm Gates Belt1
6mm x 3mm Round Neodymium Magnets23
Bowden Clipqty = 1 + N8
Bowden Fittingqty = 1 + N8
7X7 Drag chain1
cable20awg wire length 1000mm white1
cable20awg wire length 1000mm black1
cable24awg wire length 900mm1
Type C data cable1
Ties10

9 channel version:

SEE ALSO Top 10 Education Centers for Dog Trainers in the USA
ProjectsComponent SpecQty
NEMA17 Motor 14HS11-1004S35 stepper motor 35*35*28mm1
NEMA17 Motor 17HS08-1004S42 stepper motor 42*42*20mm1
Towerpro MG90S servomg90 14g tooth digital servo (S version) 180°1
Heat Sinks9*9*12 black2
TCRT5000 Sensor PCB1
ERCF ERB1
Jumper2.543
Omron Mouse Button Micro SwitchOmron mechanical limit switch D2F-01L1
AH3364Q-P-B Hall Effect sensor (SIP)1
xh2.54 male 3-pin header1
6mm x 3mm Round Neodymium Magnets1
M3 DIN125 Steel Washer1
M3x8 SHCS1
M3x8 SHCS1
N sets of Bondtech gearsBMG Gear Kit qty = N + 110
LM8UU bearings or RJ4JP-01-08LM8UU RJ4JP-01-082
M5 threaded rodsM5 Threaded Rod Length 156mm Length = 25 + N*21 + ceil(N/3 -1)*5 mm2
8mm smooth rods8mm Chrome Plated Smooth Shaft Length 171mm Length = 40 + N*21 + ceil(N/3 – 1)*5 mm2
D-cut 5mm shaftD-axis 5mm Length = 70 + N*21 + ceil(N/3 – 1)*5 mm1
MR623ZZ bearingMR623ZZ ball bearing1
MR85ZZ bearingsMR85ZZ Ball bearing6
M3 threaded insertsM3 D5 L435
M5x30 BHCS2
M5x16 BHCS1
M5 nuts5
M5 nylock nuts6
M5 washers3
M3x8 SHCS25
M3x8 BHCS5
M3x12 SHCS3
M3x16 SHCSqty = 4 + N16
M3x20 SHCS7
M3x40 SHCS2
M3 DIN125 Steel Washer15
M2x8 SHCS or M2x10 SHCS2
GT2 belt 6mm (open)GT2 Open Belt-2GT-6 (6mm width) – Gates Belt Length 450mm Length = 150 + N*42 + ceil(N/3 – 1)*10 mm1
GT2 20T Pulley 6 mm, 5mm bore3
GT2 20T Toothed Idler 6 mm, 5mm bore1
GT2 188m Belt loop 6mmGT2 Closed Belt (6mm W) – 188mm Gates Belt1
6mm x 3mm Round Neodymium Magnets32
Bowden Clipqty = 1 + N11
Bowden Fittingqty = 1 + N11
7X7 Drag chain1
cable20awg wire length 1000mm white1
cable20awg wire length 1000mm black1
cable24awg wire length 900mm1
Type C data cable1
Ties10
What needs to be self-sourced:
  • Printed parts
